| Range | 5Mpx/4Mpx PRO |
| Image sensor | SC5035 |
| DSP | FH8538M |
| Maximum resolution | Default:4Mpx - 25FPS (HDTVI, HDCVI, AHD) Opcional por menú:5Mpx - |
| Video output | 1 x BNC switchable HDTVI 2.0 / HDCVI / AHD / CVBS |
| Minimum illumination | 0 Lux / 2 IR LEDs Array (20 m) |
| Basic functions | OSD menu, Day/Night with IR-CUT (ICR) |
| Configurable OSD functions | AE, 2DNR, AWB |
| Lens | 3.6 mm |
| Power supply | DC 12 V / 300 mA max. |
| Degree of protection | Weatherproof IP66 |
| Temp. operation | -10º C ~ +45º C |
| Dimensions | 170 (D) x 58 (Ø) mm |
| Weight | 320 g |
