| Range | 5Mpx/4Mpx PRO |
| Image sensor | 1/2.5" Aptina© AR0521+FH8538M |
| DSP | FH8538M |
| Resolution | Default: 5Mpx@20FPS (HDTVI), 4Mpx@25FPS (HDCVI y AHD) Opcional por menú: 4Mpx@25FPS (HDTVI) |
| Video output | 1 x BNC switchable HDTVI 2.0 / HDCVI / AHD / CVBS |
| Minimum illumination | 0 Lux / 18 LEDs SMD IR (20 m) |
| Basic functions | OSD menu, Day/Night with IR-CUT (ICR) |
| Configurable OSD functions | AE, 2DNR, AWB |
| Lens | 3.6 mm Lens |
| Power supply | DC 12 V / 1000 mA max. |
| Degree of protection | Weatherproof IP66 |
| Temp. operation | -10º C ~ +45º C |
| Dimensions | 99 (D) x 140 (Ø) mm |
| Weight | 610 g |
