| Range | HDCVI 1080p ULTRA |
| Image sensor | 1/3" Panasonic© 2.0 Megapixel |
| Resolution | 1080p (25 fps) / 720p (25 ~ 50 fps) |
| Video output | 1 x BNC (HDCVI) / 1 x BNC (CVBS) for test |
| Infrared lighting | 0 Lux / 24 LEDs SMD IR (30 m) |
| Basic functions | OSD menu, Day/Night with IR-CUT (ICR) |
| Configurable OSD functions | WDR, SenseUp, AWB, ATR, 2D/3D-NR, Mirror/Flip |
| Lens | Varifocal 2.7 ~ 13.5 mm (H: 98º ~ 26º) |
| Power supply | DC 12 V / 400 mA |
| Degree of protection | Weatherproof IP66 |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | 89 mm (D) x 122 (Ø) mm |
| Weight | 450 g |
