| Range | HDTVI 1080p ULTRA |
| Image sensor | 1/3" Sony© 2.43 Megapixel Exmor (IMX322) |
| DSP associated with the sensor | EN773E |
| Video output | 1 x BNC (HDTVI) / 1 x BNC (CVBS PAL system) |
| HDCVI output resolution | 1080p (1920x1080) a 25 FPS / salida test 960H |
| Minimum illumination | 0 Lux / 3 LEDs IR Array (40 m) |
| Basic functions | OSD menu, Day/Night with IR-CUT (ICR) |
| Configurable OSD functions | WDR, Sense-Up, 2&3D-DNR, HLC, BLC, AWB, AGC, Mask, MD |
| Lens | Motorised varifocal with Autofocus 2.8 ~ 12mm (94º ~ 25º) |
Power supply
| DC 12 V / 450 mA |
| Degree of protection | Weatherproof IP66, Anti-vandal |
Temp. operation
| -10º C ~ +50º C |
Dimensions
| 85 (H) x 120 (Ø) mm |
Weight
| 630 g |
