| Brand | X-Security |
| Range | HDCVI 8 Mpx ULTRA |
| Image sensor | 1/2" 8 Megapixel CMOS |
| DSP | Integrated |
| Resolution | 8 Mpx, (3840x2160) at 25 FPS |
| Video output | 1 x BNC HDCVI / 1x BNC CVBS (video test) |
| Minimum illumination | 0.01Lux (Colour), 0.001lux (B/W) |
| Infrared lighting | 0 Lux / IR Range 15 m |
| Basic functions | OSD menu, Day/Night |
| Configurable OSD functions | WDR (120dB), AWB, AGC, BLC, HLC, 3DNR |
| Lens | 2.5 mm Fisheye (H: 180º) |
| Audio | Integrated microphone |
| Alarms | 2 Relay Inputs / Outputs (NO/NC) |
| Power supply | DC 12 V / 650 mA |
| Degree of protection | Weatherproof IP67, Anti-vandal IK10 |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | 48 (H) x 150 (Ø) mm |
| Weight | 560 g |
